Notebook 21: Clinical & Biomedical Imaging — Data Modalities

Notebook 21: Clinical & Biomedical Imaging — Data Modalities#

BINF 4002 — Machine Learning for Health | Lecture 21 Companion

Overview#

This notebook uses real medical images from multiple sources to generate lecture figures. The primary data sources are:

Source	Modality	What you get
MedMNIST (download)	Chest X-ray, Dermoscopy, H&E Pathology	Standardized 28×28–224×224 benchmark images with labels
pydicom (bundled)	CT, MRI	Real DICOM files with full clinical metadata
scikit-image (bundled)	Retinal fundus, IHC tissue, microscopy	High-res bundled images

Important notes on data realism:

MedMNIST images are real clinical images but downsampled (originals are much larger). They are the best freely downloadable option for this notebook.
The pydicom CT/MRI are small test files (128×128 / 64×64), not full clinical volumes (512×512×300+).
The scikit-image IHC tissue uses immunohistochemistry stain, which is visually distinct from H&E (the clinical standard). We use PathMNIST for true H&E examples when available.
The Shepp-Logan phantom in the windowing demo is a synthetic mathematical test object, not a real CT scan.

If MedMNIST download fails: The notebook falls back to bundled data only, but some figures will be less representative. See the “Extending” section at the end for manual download instructions.

!pip -qq install pydicom medmnist

/bin/bash: line 1: pip: command not found

# ==============================================================================
# Imports & Setup
# ==============================================================================
import numpy as np
import matplotlib.pyplot as plt
import matplotlib.gridspec as gridspec
from pathlib import Path
import warnings
warnings.filterwarnings("ignore")
import os

FIGURE_DIR = "./figures/"
os.makedirs(FIGURE_DIR, exist_ok=True)
os.makedirs("./medmnist_data", exist_ok=True)

import skimage.data
from skimage.transform import resize
from skimage.color import rgb2gray

import pydicom

# Try MedMNIST
try:
    import medmnist
    from medmnist import ChestMNIST, DermaMNIST, PathMNIST
    HAS_MEDMNIST = True
    print(f"medmnist {medmnist.__version__} available")
except ImportError:
    HAS_MEDMNIST = False
    print("medmnist not installed. Install with: pip install medmnist")

print(f"scikit-image {__import__('skimage').__version__}")
print(f"pydicom {pydicom.__version__}")
print(f"Figures → {os.path.abspath(FIGURE_DIR)}")

---------------------------------------------------------------------------
ModuleNotFoundError                       Traceback (most recent call last)
Cell In[2], line 16
     12 FIGURE_DIR = "./figures/"
     13 os.makedirs(FIGURE_DIR, exist_ok=True)
     14 os.makedirs("./medmnist_data", exist_ok=True)
     15
---> 16 import skimage.data
     17 from skimage.transform import resize
     18 from skimage.color import rgb2gray
     19

ModuleNotFoundError: No module named 'skimage'

# ==============================================================================
# Load MedMNIST Data (Chest X-Ray, Dermoscopy, H&E Pathology)
# ==============================================================================
MEDMNIST_LOADED = False

if HAS_MEDMNIST:
    try:
        print("Downloading MedMNIST datasets (first run only)...")
        chest_ds = ChestMNIST(split='test', download=True, size=224, root='./medmnist_data')
        derma_ds = DermaMNIST(split='test', download=True, size=224, root='./medmnist_data')
        path_ds  = PathMNIST(split='test', download=True, size=224, root='./medmnist_data')

        # Extract numpy arrays: MedMNIST returns PIL images
        def extract_images(dataset, n=50):
            imgs = []
            for i in range(min(n, len(dataset))):
                img, label = dataset[i]
                imgs.append(np.array(img))
            return np.array(imgs)

        chest_images = extract_images(chest_ds, 50)  # Grayscale chest X-rays
        derma_images = extract_images(derma_ds, 50)  # RGB dermoscopy
        path_images  = extract_images(path_ds, 50)   # RGB H&E pathology

        # Also get labels for chest X-rays
        chest_labels = np.array([chest_ds[i][1] for i in range(min(200, len(chest_ds)))])

        print(f"  ChestMNIST: {chest_images.shape} (chest X-rays, {'grayscale' if chest_images.ndim==3 else 'RGB'})")
        print(f"  DermaMNIST: {derma_images.shape} (dermoscopy)")
        print(f"  PathMNIST:  {path_images.shape} (H&E pathology)")
        print(f"  Chest labels: {chest_labels.shape}")
        MEDMNIST_LOADED = True
    except Exception as e:
        print(f"MedMNIST download failed: {e}")
        print("Falling back to bundled data only.")
        print("To fix: download .npz files manually from https://zenodo.org/records/10519652")
        print("and place them in ./medmnist_data/")

if not MEDMNIST_LOADED:
    print("\nUsing bundled data only (no chest X-ray, dermoscopy, or H&E pathology).")
    print("MedMNIST would provide these — see 'Extending' section at end.")
    chest_images = None
    derma_images = None
    path_images = None
    chest_labels = None

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
Cell In[3], line 6
      2 # Load MedMNIST Data (Chest X-Ray, Dermoscopy, H&E Pathology)
      3 # ==============================================================================
      4 MEDMNIST_LOADED = False
      5
----> 6 if HAS_MEDMNIST:
      7     try:
      8         print("Downloading MedMNIST datasets (first run only)...")
      9         chest_ds = ChestMNIST(split='test', download=True, size=224, root='./medmnist_data')

NameError: name 'HAS_MEDMNIST' is not defined

# ==============================================================================
# Load Bundled Data (always available)
# ==============================================================================

# --- scikit-image bundled ---
retina_img = skimage.data.retina()          # (1411, 1411, 3) real fundoscopy
ihc_img = skimage.data.immunohistochemistry()  # (512, 512, 3) real IHC tissue
phantom = skimage.data.shepp_logan_phantom()   # (400, 400) synthetic CT test phantom
cell_img = skimage.data.cell()              # (660, 550) real fluorescence microscopy
natural_imgs = {
    "Astronaut": skimage.data.astronaut(),
    "Coffee": skimage.data.coffee(),
    "Cat": skimage.data.cat(),
}
print("scikit-image bundled data loaded.")

# --- pydicom test DICOM ---
dcm_dir = os.path.join(os.path.dirname(pydicom.__file__), "data", "test_files")
ct_dcm = pydicom.dcmread(os.path.join(dcm_dir, "CT_small.dcm"))
mr_dcm = pydicom.dcmread(os.path.join(dcm_dir, "MR_small.dcm"))
ct_pixels = ct_dcm.pixel_array.astype(np.float64)
mr_pixels = mr_dcm.pixel_array.astype(np.float64)
print(f"CT DICOM: {ct_pixels.shape}, Manufacturer: {ct_dcm.Manufacturer}")
print(f"MR DICOM: {mr_pixels.shape}, Manufacturer: {mr_dcm.Manufacturer}")
print("Note: These are small test DICOMs. Real clinical CT is 512×512×300+.")

print("\nAll data loaded.")

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
Cell In[4], line 6
      2 # Load Bundled Data (always available)
      3 # ==============================================================================
      4
      5 # --- scikit-image bundled ---
----> 6 retina_img = skimage.data.retina()          # (1411, 1411, 3) real fundoscopy
      7 ihc_img = skimage.data.immunohistochemistry()  # (512, 512, 3) real IHC tissue
      8 phantom = skimage.data.shepp_logan_phantom()   # (400, 400) synthetic CT test phantom
      9 cell_img = skimage.data.cell()              # (660, 550) real fluorescence microscopy

NameError: name 'skimage' is not defined

Individual Modality Examples (for slides)#

Save individual example images for slide inclusion via \includegraphics.

# Save individual modality example images for slides
print("Saving individual modality examples...")

if MEDMNIST_LOADED:
    fig, ax = plt.subplots(1, 1, figsize=(4, 4))
    cxr = chest_images[0]
    ax.imshow(cxr[:,:,0] if cxr.ndim == 3 else cxr, cmap="gray")
    ax.set_title("Chest X-Ray (ChestMNIST)", fontweight='bold')
    ax.axis("off"); plt.tight_layout()
    plt.savefig(f"{FIGURE_DIR}example_xray.png", bbox_inches="tight", dpi=150); plt.close()

fig, ax = plt.subplots(1, 1, figsize=(4, 4))
ax.imshow(ct_pixels, cmap="gray")
ax.set_title("CT Slice (pydicom)", fontweight='bold')
ax.axis("off"); plt.tight_layout()
plt.savefig(f"{FIGURE_DIR}example_ct.png", bbox_inches="tight", dpi=150); plt.close()

fig, ax = plt.subplots(1, 1, figsize=(4, 4))
ax.imshow(mr_pixels, cmap="gray")
ax.set_title("MRI Slice (pydicom)", fontweight='bold')
ax.axis("off"); plt.tight_layout()
plt.savefig(f"{FIGURE_DIR}example_mri.png", bbox_inches="tight", dpi=150); plt.close()

h, w = retina_img.shape[:2]; crop=512; cy,cx = h//2, w//2
fig, ax = plt.subplots(1, 1, figsize=(4, 4))
ax.imshow(retina_img[cy-crop//2:cy+crop//2, cx-crop//2:cx+crop//2])
ax.set_title("Retinal Fundus", fontweight='bold')
ax.axis("off"); plt.tight_layout()
plt.savefig(f"{FIGURE_DIR}example_retinal.png", bbox_inches="tight", dpi=150); plt.close()

if MEDMNIST_LOADED:
    for name, imgs in [("derm", derma_images), ("pathology", path_images)]:
        fig, ax = plt.subplots(1, 1, figsize=(4, 4))
        ax.imshow(imgs[0]); ax.axis("off"); plt.tight_layout()
        plt.savefig(f"{FIGURE_DIR}example_{name}.png", bbox_inches="tight", dpi=150); plt.close()

print("Done. Use \\includegraphics{figures/example_*.png} in slides.")

Saving individual modality examples...

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
Cell In[5], line 13
      9     ax.axis("off"); plt.tight_layout()
     10     plt.savefig(f"{FIGURE_DIR}example_xray.png", bbox_inches="tight", dpi=150); plt.close()
     11
     12 fig, ax = plt.subplots(1, 1, figsize=(4, 4))
---> 13 ax.imshow(ct_pixels, cmap="gray")
     14 ax.set_title("CT Slice (pydicom)", fontweight='bold')
     15 ax.axis("off"); plt.tight_layout()
     16 plt.savefig(f"{FIGURE_DIR}example_ct.png", bbox_inches="tight", dpi=150); plt.close()

NameError: name 'ct_pixels' is not defined

../_images/6bf90d4eac622f7256bd0436f7dc9f217e38f07b16b877e8659ce10255822697.png

Figure 1: Visual Survey — Medical Images Across Modalities#

LECTURE FIGURE (slides: “Real Medical Images Across Modalities”)

Side-by-side comparison of real images from each modality. If MedMNIST loaded, you’ll see actual chest X-rays, dermoscopy, and H&E pathology alongside CT, MRI, retinal, and natural images.

# Figure 1: Medical vs Natural images — clearer side-by-side comparison
import matplotlib.pyplot as plt
import matplotlib.gridspec as gridspec
import numpy as np

# -----------------------------
# Assemble images
# -----------------------------
if MEDMNIST_LOADED:
    medical_imgs = [
        ("Chest X-Ray\n(ChestMNIST)", chest_images[0], "gray"),
        ("CT\n(DICOM, GE)", ct_pixels, "gray"),
        ("MRI\n(DICOM, Toshiba)", mr_pixels, "gray"),
        ("Retinal Fundus\n(scikit-image)", retina_img, None),
        ("Dermoscopy\n(DermaMNIST)", derma_images[0], None),
        ("H&E Pathology\n(PathMNIST)", path_images[0], None),
    ]
else:
    medical_imgs = [
        ("CT\n(DICOM, GE)", ct_pixels, "gray"),
        ("MRI\n(DICOM, Toshiba)", mr_pixels, "gray"),
        ("Retinal Fundus", retina_img, None),
        ("IHC Tissue\n(NOT H&E)", ihc_img, None),
        ("Cell Microscopy", cell_img, "gray"),
        ("Shepp-Logan\n(synthetic)", phantom, "gray"),
    ]

# Use all three bundled natural images so the comparison actually reads as a category
natural_imgs_list = [
    ("Astronaut", natural_imgs["Astronaut"], None),
    ("Coffee", natural_imgs["Coffee"], None),
    ("Cat", natural_imgs["Cat"], None),
]

# -----------------------------
# Helper for display
# -----------------------------
def prepare_for_display(img, cmap=None, crop_square=True):
    arr = np.asarray(img)

    # squeeze singleton channel
    if arr.ndim == 3 and arr.shape[-1] == 1:
        arr = arr[:, :, 0]

    # grayscale MedMNIST sometimes comes as 3 identical channels
    if cmap == "gray" and arr.ndim == 3:
        arr = arr[:, :, 0]

    # center-crop very non-square images so the grid looks intentional
    if crop_square:
        h, w = arr.shape[:2]
        if max(h, w) / min(h, w) > 1.2:
            side = min(h, w)
            y0 = (h - side) // 2
            x0 = (w - side) // 2
            arr = arr[y0:y0+side, x0:x0+side]

    return arr

def draw_panel(ax, title, img, cmap, title_color):
    arr = prepare_for_display(img, cmap=cmap, crop_square=True)
    if arr.ndim == 2:
        ax.imshow(arr, cmap=cmap or "gray")
    else:
        ax.imshow(arr)
    ax.set_title(title, fontsize=10, fontweight="bold", color=title_color, pad=6)
    ax.set_xticks([])
    ax.set_yticks([])
    for spine in ax.spines.values():
        spine.set_visible(True)
        spine.set_linewidth(1.0)
        spine.set_edgecolor("#DDDDDD")

# -----------------------------
# Layout
# -----------------------------
fig = plt.figure(figsize=(15, 8), constrained_layout=False)
outer = gridspec.GridSpec(
    1, 2, figure=fig,
    width_ratios=[3.2, 1.25],
    wspace=0.12
)

medical_gs = gridspec.GridSpecFromSubplotSpec(
    2, 3, subplot_spec=outer[0],
    hspace=0.28, wspace=0.18
)

natural_gs = gridspec.GridSpecFromSubplotSpec(
    3, 1, subplot_spec=outer[1],
    hspace=0.25
)

# Left: 6 medical panels
for i, (title, img, cmap) in enumerate(medical_imgs):
    ax = fig.add_subplot(medical_gs[i // 3, i % 3])
    draw_panel(ax, title, img, cmap, title_color="#1D4F91")

# Right: 3 natural panels
for i, (title, img, cmap) in enumerate(natural_imgs_list):
    ax = fig.add_subplot(natural_gs[i, 0])
    draw_panel(ax, title, img, cmap, title_color="#666666")

# -----------------------------
# Titles / annotations
# -----------------------------
status = "with MedMNIST" if MEDMNIST_LOADED else "bundled only"

fig.suptitle(
    "Figure 1: Medical Imaging vs. Natural Images",
    fontsize=16, fontweight="bold", y=0.985
)

fig.text(
    0.33, 0.935, "Medical imaging modalities",
    fontsize=13, fontweight="bold", color="#1D4F91", ha="center"
)
fig.text(
    0.84, 0.935, "Natural images",
    fontsize=13, fontweight="bold", color="#666666", ha="center"
)
fig.text(
    0.73, 0.52, "vs.",
    fontsize=22, fontweight="bold", color="#999999", ha="center", va="center"
)

plt.savefig(f"{FIGURE_DIR}fig1_visual_survey.pdf", bbox_inches="tight", dpi=150)
plt.savefig(f"{FIGURE_DIR}fig1_visual_survey.png", bbox_inches="tight", dpi=150)
plt.show()

print(f"Saved fig1_visual_survey.* ({status})")

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
Cell In[6], line 20
     16         ("H&E Pathology\n(PathMNIST)", path_images[0], None),
     17     ]
     18 else:
     19     medical_imgs = [
---> 20         ("CT\n(DICOM, GE)", ct_pixels, "gray"),
     21         ("MRI\n(DICOM, Toshiba)", mr_pixels, "gray"),
     22         ("Retinal Fundus", retina_img, None),
     23         ("IHC Tissue\n(NOT H&E)", ihc_img, None),

NameError: name 'ct_pixels' is not defined

Figure 2: Pixel Intensity Distributions#

LECTURE FIGURE (appendix; see notebook for interactive exploration)

Each modality has a characteristic intensity distribution.

n_panels = 6 if MEDMNIST_LOADED else 4
fig, axes = plt.subplots(2, 3, figsize=(16, 8))

# Panel 1: Chest X-ray or CT
ax = axes[0, 0]
if MEDMNIST_LOADED:
    # Chest X-rays — may be RGB (3-channel grayscale) or actual grayscale
    cxr = chest_images[:20]
    if cxr.ndim == 4 and cxr.shape[-1] == 3:
        cxr_gray = cxr[:,:,:,0]  # All channels identical for grayscale
    else:
        cxr_gray = cxr
    ax.hist(cxr_gray.flatten(), bins=80, color="#1D4F91", alpha=0.8, density=True)
    ax.set_title("Chest X-Ray (ChestMNIST)", fontsize=11, fontweight='bold')
else:
    ax.hist(ct_pixels.flatten(), bins=80, color="#1D4F91", alpha=0.8, density=True)
    ax.set_title("CT (Hounsfield Units)", fontsize=11, fontweight='bold')
ax.set_xlabel("Pixel Intensity")
ax.set_ylabel("Density")

# Panel 2: MRI
ax = axes[0, 1]
ax.hist(mr_pixels.flatten(), bins=80, color="#1D4F91", alpha=0.8, density=True)
ax.set_title("MRI (Arbitrary Intensity)", fontsize=11, fontweight='bold')
ax.set_xlabel("Signal Intensity")
ax.annotate("No standardized\nscale", xy=(0.65, 0.85), xycoords='axes fraction',
            fontsize=8, fontstyle='italic', color='#D2492A')

# Panel 3: Retinal fundus
ax = axes[0, 2]
for c, (color, label) in enumerate(zip(["red", "green", "blue"], ["R", "G", "B"])):
    ax.hist(retina_img[:,:,c].flatten(), bins=100, color=color,
            alpha=0.5, density=True, label=label)
ax.set_title("Retinal Fundus (RGB)", fontsize=11, fontweight='bold')
ax.set_xlabel("Pixel Intensity")
ax.legend(fontsize=9)

# Panel 4: Pathology
ax = axes[1, 0]
if MEDMNIST_LOADED:
    path_sample = path_images[:20]
    for c, (color, label) in enumerate(zip(["red", "green", "blue"], ["R", "G", "B"])):
        ax.hist(path_sample[:,:,:,c].flatten(), bins=100, color=color,
                alpha=0.5, density=True, label=label)
    ax.set_title("H&E Pathology (PathMNIST)", fontsize=11, fontweight='bold')
else:
    for c, (color, label) in enumerate(zip(["red", "green", "blue"], ["R", "G", "B"])):
        ax.hist(ihc_img[:,:,c].flatten(), bins=100, color=color,
                alpha=0.5, density=True, label=label)
    ax.set_title("IHC Tissue (NOT H&E)", fontsize=11, fontweight='bold')
ax.set_xlabel("Pixel Intensity")
ax.legend(fontsize=9)

# Panel 5: Dermoscopy or Cell
ax = axes[1, 1]
if MEDMNIST_LOADED:
    derma_sample = derma_images[:20]
    for c, (color, label) in enumerate(zip(["red", "green", "blue"], ["R", "G", "B"])):
        ax.hist(derma_sample[:,:,:,c].flatten(), bins=100, color=color,
                alpha=0.5, density=True, label=label)
    ax.set_title("Dermoscopy (DermaMNIST)", fontsize=11, fontweight='bold')
else:
    ax.hist(cell_img.flatten(), bins=100, color="#2E8B57", alpha=0.8, density=True)
    ax.set_title("Cell Microscopy", fontsize=11, fontweight='bold')
ax.set_xlabel("Pixel Intensity")
if MEDMNIST_LOADED:
    ax.legend(fontsize=9)

# Panel 6: Natural
ax = axes[1, 2]
natural = natural_imgs["Astronaut"]
for c, (color, label) in enumerate(zip(["red", "green", "blue"], ["R", "G", "B"])):
    ax.hist(natural[:,:,c].flatten(), bins=100, color=color,
            alpha=0.5, density=True, label=label)
ax.set_title("Natural Image (RGB)", fontsize=11, fontweight='bold')
ax.set_xlabel("Pixel Intensity")
ax.legend(fontsize=9)

plt.suptitle("Figure 2: Pixel Intensity Distributions by Modality",
             fontsize=13, fontweight="bold", y=1.02)
plt.tight_layout()
plt.savefig(f"{FIGURE_DIR}fig2_intensity_distributions.pdf", bbox_inches="tight", dpi=150)
plt.savefig(f"{FIGURE_DIR}fig2_intensity_distributions.png", bbox_inches="tight", dpi=150)
plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
Cell In[7], line 16
     12         cxr_gray = cxr
     13     ax.hist(cxr_gray.flatten(), bins=80, color="#1D4F91", alpha=0.8, density=True)
     14     ax.set_title("Chest X-Ray (ChestMNIST)", fontsize=11, fontweight='bold')
     15 else:
---> 16     ax.hist(ct_pixels.flatten(), bins=80, color="#1D4F91", alpha=0.8, density=True)
     17     ax.set_title("CT (Hounsfield Units)", fontsize=11, fontweight='bold')
     18 ax.set_xlabel("Pixel Intensity")
     19 ax.set_ylabel("Density")

NameError: name 'ct_pixels' is not defined

../_images/14c98c761af21725be6b399af4609ce4ed9f05b9617cc38d2554843ada81c75e.png

Figure 3: Frequency Domain Analysis (Appendix)#

Radially averaged PSD for each modality. Medical images have more low-frequency energy than natural images.

def compute_radial_psd(image_2d):
    f_shift = np.fft.fftshift(np.fft.fft2(image_2d))
    magnitude = np.abs(f_shift)**2
    h, w = magnitude.shape
    cy, cx = h // 2, w // 2
    Y, X = np.ogrid[:h, :w]
    R = np.sqrt((X - cx)**2 + (Y - cy)**2).astype(int)
    max_r = min(cy, cx)
    radial_psd = np.zeros(max_r)
    for r in range(max_r):
        mask = R == r
        if mask.sum() > 0:
            radial_psd[r] = magnitude[mask].mean()
    return radial_psd

def to_gray_256(img):
    if img.ndim == 3:
        gray = rgb2gray(img)
    else:
        gray = img.astype(np.float64)
        if gray.max() > 1.0:
            gray = gray / gray.max()
    return resize(gray, (256, 256), anti_aliasing=True)

# Build modality dict
psd_images = {}
if MEDMNIST_LOADED:
    cxr0 = chest_images[0]
    if cxr0.ndim == 3:
        cxr0 = cxr0[:,:,0]
    psd_images["Chest X-Ray"] = to_gray_256(cxr0)
psd_images["CT (DICOM)"] = to_gray_256(ct_pixels)
psd_images["Retinal Fundus"] = to_gray_256(retina_img)
if MEDMNIST_LOADED:
    psd_images["H&E Pathology"] = to_gray_256(path_images[0])
else:
    psd_images["IHC Tissue"] = to_gray_256(ihc_img)
psd_images["Natural (Astronaut)"] = to_gray_256(natural_imgs["Astronaut"])

colors = {"Chest X-Ray": "#1D4F91", "CT (DICOM)": "#75AAdb",
          "Retinal Fundus": "#D2492A", "H&E Pathology": "#2E8B57",
          "IHC Tissue": "#2E8B57", "Natural (Astronaut)": "#757575"}

fig, ax = plt.subplots(1, 1, figsize=(8, 5))
for name, img in psd_images.items():
    psd = compute_radial_psd(img)
    freqs = np.arange(len(psd))
    ax.loglog(freqs[1:], psd[1:], label=name, color=colors.get(name, "#333"), linewidth=2)

ax.set_xlabel("Spatial Frequency (cycles/image)")
ax.set_ylabel("Power Spectral Density")
ax.set_title("Radial PSD by Modality", fontweight="bold")
ax.legend(fontsize=9)
ax.grid(True, alpha=0.3)

plt.tight_layout()
plt.savefig(f"{FIGURE_DIR}fig3_frequency_analysis.pdf", bbox_inches="tight", dpi=150)
plt.savefig(f"{FIGURE_DIR}fig3_frequency_analysis.png", bbox_inches="tight", dpi=150)
plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
Cell In[8], line 32
     28     cxr0 = chest_images[0]
     29     if cxr0.ndim == 3:
     30         cxr0 = cxr0[:,:,0]
     31     psd_images["Chest X-Ray"] = to_gray_256(cxr0)
---> 32 psd_images["CT (DICOM)"] = to_gray_256(ct_pixels)
     33 psd_images["Retinal Fundus"] = to_gray_256(retina_img)
     34 if MEDMNIST_LOADED:
     35     psd_images["H&E Pathology"] = to_gray_256(path_images[0])

NameError: name 'ct_pixels' is not defined

Figure 4: Augmentation Validity#

LECTURE FIGURE (slide: “Augmentation Validity: What’s Safe?”)

Demonstrated on a real retinal fundus image.

from scipy.ndimage import rotate as ndimage_rotate, gaussian_filter

h, w = retina_img.shape[:2]
crop_size = 512
cy, cx = h // 2, w // 2
retina_crop = retina_img[cy-crop_size//2:cy+crop_size//2, cx-crop_size//2:cx+crop_size//2].copy()
retina_float = retina_crop.astype(np.float64) / 255.0

augmentations = {
    "(a) Original": retina_float,
    "(b) Horiz. Flip\n✓ VALID": np.fliplr(retina_float),
    "(c) Vert. Flip\n✗ INVALID": np.flipud(retina_float),
    "(d) Rotate 15°\n✓ VALID": ndimage_rotate(retina_float, 15, reshape=False, mode="constant", cval=0),
    "(e) Color Jitter\n✗ RISKY": np.clip(retina_float * np.array([1.3, 0.8, 0.8]) + 0.05, 0, 1),
    "(f) Heavy Blur σ=5\n✗ INVALID": gaussian_filter(retina_float, sigma=(5, 5, 0)),
}

fig, axes = plt.subplots(1, 6, figsize=(18, 3.5))
for ax, (title, img) in zip(axes, augmentations.items()):
    ax.imshow(np.clip(img, 0, 1))
    valid = "✓" in title
    invalid = "✗" in title
    color = "#2E8B57" if valid else "#D2492A" if invalid else "#1D4F91"
    ax.set_title(title, fontsize=9, color=color, fontweight="bold")
    ax.axis("off")
    for spine in ax.spines.values():
        spine.set_visible(True)
        spine.set_color(color)
        spine.set_linewidth(2)

plt.suptitle("Figure 4: Augmentation Validity — Real Retinal Fundus",
             fontsize=13, fontweight="bold", y=1.05)
plt.tight_layout()
plt.savefig(f"{FIGURE_DIR}fig4_augmentation_validity.pdf", bbox_inches="tight", dpi=150)
plt.savefig(f"{FIGURE_DIR}fig4_augmentation_validity.png", bbox_inches="tight", dpi=150)
plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
Cell In[9], line 3
      1 from scipy.ndimage import rotate as ndimage_rotate, gaussian_filter
      2
----> 3 h, w = retina_img.shape[:2]
      4 crop_size = 512
      5 cy, cx = h // 2, w // 2
      6 retina_crop = retina_img[cy-crop_size//2:cy+crop_size//2, cx-crop_size//2:cx+crop_size//2].copy()

NameError: name 'retina_img' is not defined

Figure 5: Multi-Scale Visualization#

LECTURE FIGURE (slide: “Multi-Scale: Real IHC Tissue”)

If MedMNIST loaded, we show H&E pathology at multiple simulated magnifications. Otherwise, IHC tissue is used as a stand-in. Note: IHC (immunohistochemistry) uses antibody-based staining and is visually distinct from H&E (hematoxylin & eosin), which is the clinical standard.

if MEDMNIST_LOADED:
    tile_full = path_images[0]
    stain_label = "H&E Pathology (PathMNIST)"
else:
    tile_full = ihc_img
    stain_label = "IHC Tissue (scikit-image, NOT H&E)"

def downsample_and_display(img, factor, target_size=None):
    if target_size is None:
        target_size = img.shape[0]
    small = resize(img, (img.shape[0]//factor, img.shape[1]//factor), anti_aliasing=True)
    return resize(small, (target_size, target_size), order=0, anti_aliasing=False)

target = tile_full.shape[0]
scales = [
    (f"40× — Nuclear detail", tile_full),
    (f"20× — Cellular morphology", downsample_and_display(tile_full, 2, target)),
    (f"10× — Gland/structure", downsample_and_display(tile_full, 4, target)),
    (f"5× — Tissue architecture", downsample_and_display(tile_full, 8, target)),
]

fig, axes = plt.subplots(1, 4, figsize=(16, 4))
for ax, (title, img) in zip(axes, scales):
    ax.imshow(img)
    ax.set_title(title, fontsize=10, fontweight="bold")
    ax.axis("off")

plt.suptitle(f"Figure 5: Multi-Scale Visualization — {stain_label}",
             fontsize=13, fontweight="bold", y=1.03)
plt.tight_layout()
plt.savefig(f"{FIGURE_DIR}fig5_multiscale_pathology.pdf", bbox_inches="tight", dpi=150)
plt.savefig(f"{FIGURE_DIR}fig5_multiscale_pathology.png", bbox_inches="tight", dpi=150)
plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
Cell In[10], line 5
      1 if MEDMNIST_LOADED:
      2     tile_full = path_images[0]
      3     stain_label = "H&E Pathology (PathMNIST)"
      4 else:
----> 5     tile_full = ihc_img
      6     stain_label = "IHC Tissue (scikit-image, NOT H&E)"
      7
      8 def downsample_and_display(img, factor, target_size=None):

NameError: name 'ihc_img' is not defined

Figure 6: DICOM Metadata Comparison#

LECTURE FIGURE (slides: “DICOM: The Universal Standard”, “Real DICOM Metadata Comparison”)

Real DICOM files + windowing demo on the Shepp-Logan phantom (a synthetic mathematical test object with values mapped to a HU-like range for demonstration).

# Figure 6: DICOM Metadata Comparison (separate from windowing)
fig, axes = plt.subplots(1, 3, figsize=(15, 5))

ax = axes[0]
ax.imshow(ct_pixels, cmap="gray")
ax.set_title("CT Image (GE Medical)", fontsize=11, fontweight="bold")
ax.axis("off")
meta = (f"Manufacturer: {ct_dcm.Manufacturer}\n"
        f"PixelSpacing: {[round(float(x),3) for x in ct_dcm.PixelSpacing]} mm\n"
        f"SliceThickness: {float(ct_dcm.SliceThickness)} mm\n"
        f"BitsStored: {ct_dcm.BitsStored}")
ax.text(0.02, 0.02, meta, transform=ax.transAxes, fontsize=7, va='bottom',
        fontfamily='monospace', bbox=dict(boxstyle='round', facecolor='black', alpha=0.7), color='white')

ax = axes[1]
ax.imshow(mr_pixels, cmap="gray")
ax.set_title("MRI Image (Toshiba)", fontsize=11, fontweight="bold")
ax.axis("off")
meta = (f"Manufacturer: {mr_dcm.Manufacturer}\n"
        f"PixelSpacing: {[round(float(x),4) for x in mr_dcm.PixelSpacing]} mm\n"
        f"SliceThickness: {float(mr_dcm.SliceThickness)} mm\n"
        f"WindowCenter: {mr_dcm.WindowCenter}")
ax.text(0.02, 0.02, meta, transform=ax.transAxes, fontsize=7, va='bottom',
        fontfamily='monospace', bbox=dict(boxstyle='round', facecolor='black', alpha=0.7), color='white')

ax = axes[2]
ax.axis("off")
ax.set_title("Key Differences for ML", fontsize=11, fontweight="bold")
table_data = [
    ["Field", "CT (GE)", "MR (Toshiba)"],
    ["PixelSpacing", f"{float(ct_dcm.PixelSpacing[0]):.3f} mm", f"{float(mr_dcm.PixelSpacing[0]):.4f} mm"],
    ["SliceThickness", f"{float(ct_dcm.SliceThickness):.1f} mm", f"{float(mr_dcm.SliceThickness):.1f} mm"],
    ["Intensity", "Hounsfield (std)", "Arbitrary (!)"],
]
table = ax.table(cellText=table_data, loc='center', cellLoc='center')
table.auto_set_font_size(False); table.set_fontsize(9); table.scale(1.0, 1.8)
for j in range(3):
    table[0, j].set_facecolor('#1D4F91')
    table[0, j].set_text_props(color='white', fontweight='bold')

plt.suptitle("Figure 6: DICOM Metadata — CT vs. MRI", fontsize=13, fontweight="bold", y=1.02)
plt.tight_layout()
plt.savefig(f"{FIGURE_DIR}fig6_dicom_metadata.pdf", bbox_inches="tight", dpi=150)
plt.savefig(f"{FIGURE_DIR}fig6_dicom_metadata.png", bbox_inches="tight", dpi=150)
plt.show()

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
Cell In[11], line 5
      1 # Figure 6: DICOM Metadata Comparison (separate from windowing)
      2 fig, axes = plt.subplots(1, 3, figsize=(15, 5))
      3
      4 ax = axes[0]
----> 5 ax.imshow(ct_pixels, cmap="gray")
      6 ax.set_title("CT Image (GE Medical)", fontsize=11, fontweight="bold")
      7 ax.axis("off")
      8 meta = (f"Manufacturer: {ct_dcm.Manufacturer}\n"

NameError: name 'ct_pixels' is not defined

../_images/acb63c42352105208b08d9a404ac31f3a6b674b8cc70edd1e9baaee84cd0d4bf.png

Figure 8: CT Windowing Demo#

LECTURE FIGURE (slide: “CT: Windowing Matters”)

W (width) and L (level/center) define which Hounsfield unit range maps to the display. L sets the center; W sets how wide. Everything outside clips to black or white.

Applied to both the real pydicom CT and the Shepp-Logan phantom (synthetic test object).

# Figure 8: CT Windowing — real DICOM + phantom (FIXED)
import numpy as np
import matplotlib.pyplot as plt

def apply_window(image_hu, center, width):
    lower = center - width / 2
    upper = center + width / 2
    return np.clip((image_hu - lower) / (upper - lower), 0, 1)

# Convert stored DICOM values to Hounsfield Units
slope = float(getattr(ct_dcm, "RescaleSlope", 1.0))
intercept = float(getattr(ct_dcm, "RescaleIntercept", 0.0))
ct_hu = ct_pixels * slope + intercept

fig, axes = plt.subplots(2, 4, figsize=(16, 7))

windows = [
    ("Full Range\n(HU)", ct_hu.mean(), ct_hu.max() - ct_hu.min()),
    ("Soft Tissue\nL=40, W=400", 40, 400),
    ("Lung\nL=-600, W=1500", -600, 1500),
    ("Bone\nL=400, W=1800", 400, 1800),
]

# Row 1: Real CT DICOM in HU
for ax, (title, c, w) in zip(axes[0], windows):
    ax.imshow(apply_window(ct_hu, c, w), cmap="gray", vmin=0, vmax=1)
    ax.set_title(title, fontsize=10, fontweight="bold")
    ax.axis("off")
axes[0][0].set_ylabel("Real CT\n(HU-corrected)", fontsize=11, fontweight="bold")

# Row 2: Shepp-Logan phantom (synthetic, mapped to HU-like range)
hu_phantom = phantom * 2000 - 1000
for ax, (title, c, w) in zip(axes[1], windows):
    ax.imshow(apply_window(hu_phantom, c, w), cmap="gray", vmin=0, vmax=1)
    ax.set_title(title, fontsize=10, fontweight="bold")
    ax.axis("off")
axes[1][0].set_ylabel("Phantom\n(synthetic)", fontsize=11, fontweight="bold")

plt.suptitle("Figure 8: CT Windowing — Same Data, Different Views",
             fontsize=13, fontweight="bold", y=1.02)
plt.tight_layout()
plt.savefig(f"{FIGURE_DIR}fig8_ct_windowing_real.pdf", bbox_inches="tight", dpi=150)
plt.savefig(f"{FIGURE_DIR}fig8_ct_windowing_real.png", bbox_inches="tight", dpi=150)
plt.show()

print(f"CT stored-value range: {ct_pixels.min():.1f} to {ct_pixels.max():.1f}")
print(f"CT HU range: {ct_hu.min():.1f} to {ct_hu.max():.1f}")
print(f"Using RescaleSlope={slope}, RescaleIntercept={intercept}")

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
Cell In[12], line 11
      7     upper = center + width / 2
      8     return np.clip((image_hu - lower) / (upper - lower), 0, 1)
      9
     10 # Convert stored DICOM values to Hounsfield Units
---> 11 slope = float(getattr(ct_dcm, "RescaleSlope", 1.0))
     12 intercept = float(getattr(ct_dcm, "RescaleIntercept", 0.0))
     13 ct_hu = ct_pixels * slope + intercept
     14

NameError: name 'ct_dcm' is not defined

DICOM Deep Dive#

Explore all metadata fields in the real CT and MR DICOM files.

fields = ['Modality', 'Manufacturer', 'PatientPosition', 'PixelSpacing',
         'SliceThickness', 'Rows', 'Columns', 'BitsStored',
         'RescaleIntercept', 'RescaleSlope', 'WindowCenter', 'WindowWidth']

for name, ds in [("CT (GE MEDICAL SYSTEMS)", ct_dcm), ("MR (TOSHIBA_MEC)", mr_dcm)]:
    print(f"{'='*60}")
    print(f"{name}")
    print(f"{'='*60}")
    for field in fields:
        val = getattr(ds, field, 'N/A')
        if val != 'N/A':
            print(f"  {field:25s} = {val}")
    print()

print("In a real pipeline, you MUST check PixelSpacing, RescaleSlope/Intercept,")
print("and WindowCenter/Width before feeding images to a model.")

---------------------------------------------------------------------------
NameError                                 Traceback (most recent call last)
Cell In[13], line 5
      1 fields = ['Modality', 'Manufacturer', 'PatientPosition', 'PixelSpacing',
      2          'SliceThickness', 'Rows', 'Columns', 'BitsStored',
      3          'RescaleIntercept', 'RescaleSlope', 'WindowCenter', 'WindowWidth']
      4
----> 5 for name, ds in [("CT (GE MEDICAL SYSTEMS)", ct_dcm), ("MR (TOSHIBA_MEC)", mr_dcm)]:
      6     print(f"{'='*60}")
      7     print(f"{name}")
      8     print(f"{'='*60}")

NameError: name 'ct_dcm' is not defined

Label Distribution (if MedMNIST available)#

Chest X-ray datasets exhibit extreme class imbalance and multi-label structure.

if MEDMNIST_LOADED and chest_labels is not None:
    PATHOLOGY_NAMES = [
        "Atelectasis", "Cardiomegaly", "Effusion", "Infiltration",
        "Mass", "Nodule", "Pneumonia", "Pneumothorax",
        "Consolidation", "Edema", "Emphysema", "Fibrosis",
        "Pleural Thickening", "Hernia"
    ]

    fig, axes = plt.subplots(1, 2, figsize=(14, 5))

    # (a) Label frequency
    ax = axes[0]
    label_counts = chest_labels.sum(axis=0).flatten()
    no_finding = (chest_labels.sum(axis=1) == 0).sum()

    names = PATHOLOGY_NAMES + ["No Finding"]
    counts = list(label_counts) + [no_finding]
    sort_idx = np.argsort(counts)[::-1]

    colors_bar = ["#D2492A" if names[i] == "No Finding" else "#1D4F91" for i in sort_idx]
    ax.barh(range(len(names)), [counts[i] for i in sort_idx], color=colors_bar, alpha=0.8)
    ax.set_yticks(range(len(names)))
    ax.set_yticklabels([names[i] for i in sort_idx], fontsize=8)
    ax.set_xlabel("Count")
    ax.set_title("(a) Label Frequency (ChestMNIST test)", fontweight="bold")
    ax.invert_yaxis()

    # (b) Labels per image
    ax = axes[1]
    n_per = chest_labels.sum(axis=1).flatten()
    bins = np.arange(-0.5, max(n_per) + 1.5, 1)
    ax.hist(n_per, bins=bins, color="#1D4F91", alpha=0.8, edgecolor="white")
    ax.set_xlabel("Number of Positive Labels")
    ax.set_ylabel("Number of Images")
    ax.set_title("(b) Labels per Image", fontweight="bold")

    plt.suptitle("Chest X-Ray Label Distribution (ChestMNIST)", fontsize=13, fontweight="bold", y=1.02)
    plt.tight_layout()
    plt.savefig(f"{FIGURE_DIR}fig7_label_distribution.pdf", bbox_inches="tight", dpi=150)
    plt.savefig(f"{FIGURE_DIR}fig7_label_distribution.png", bbox_inches="tight", dpi=150)
    plt.show()
else:
    print("MedMNIST not loaded — skipping label distribution figure.")
    print("With ChestMNIST, this would show extreme class imbalance")
    print("('No Finding' dominates) and multi-label co-occurrence.")

MedMNIST not loaded — skipping label distribution figure.
With ChestMNIST, this would show extreme class imbalance
('No Finding' dominates) and multi-label co-occurrence.

Discussion Questions#

DICOM metadata: The CT and MRI above come from different manufacturers with different pixel spacings. If you trained on GE CT (0.66 mm/px) and tested on Siemens CT (0.49 mm/px), what would go wrong? How would you normalize?
Windowing as feature engineering: The lung window reveals structures invisible in the bone window. If your model needs to detect both lung nodules and rib fractures, what input strategy would you use?
Augmentation by modality: Compare the retinal augmentation results to what you’d expect for chest X-rays. Which augmentations transfer? Which are modality-specific?
Label granularity: ChestMNIST has image-level multi-labels. What would you need for a detection model (finding the nodule’s location)? How much more expensive is that?
Data access: Why does this notebook use MedMNIST’s downsampled images rather than full-resolution clinical data? What does that tell you about imaging data accessibility?

Extending with Additional Datasets#

If MedMNIST download failed, download .npz files manually:

ChestMNIST: https://zenodo.org/records/10519652/files/chestmnist_224.npz
DermaMNIST: https://zenodo.org/records/10519652/files/dermamnist_224.npz
PathMNIST: https://zenodo.org/records/10519652/files/pathmnist_224.npz

Place in ./medmnist_data/ and re-run.

For full-resolution clinical data (requires credentialing):

NIH ChestX-ray14: https://nihcc.app.box.com/v/ChestXray-NIHCC
CheXpert (Stanford): https://stanfordmlgroup.github.io/competitions/chexpert/
MIMIC-CXR (PhysioNet): https://physionet.org/content/mimic-cxr/
ISIC Dermoscopy: https://www.isic-archive.com/
TCGA Pathology WSIs: https://portal.gdc.cancer.gov/

Summary#

This notebook used real medical images from multiple sources. Key takeaways:

Different modalities have fundamentally different intensity distributions — normalization must be modality-aware
DICOM metadata (pixel spacing, manufacturer, window settings) directly affects model performance
CT windowing is a preprocessing choice that determines what your model can detect
Augmentations must respect physics — validity depends on the modality
Label structure (image-level, study-level, pixel-level) determines what tasks are feasible

Next: Thursday’s lecture (L22) — transfer learning, U-Net, MIL, foundation models.
